DEYE 15KW THREE PHASE STRING INVERTER

Description10 YEARS WARRANTYDEYE 15KW THREE PHASE STRING INVERTER (SUN-15K-G06P3-EU-AM2-P1)5 Years WarrantyInput (DC Side):Max. PV Input Power: 7.5kWMax. PV Input Voltage: 550VStart-up Voltage: 80VMPPT Voltage Range: 70 – 500VRated PV Input Voltage: 360VMax. Operating PV Input Current: 18A 18AMax. Short Circuit Current: 27A 27AMPPT Trackers: 2Strings per MPPT: 1 1Output (AC Side):Rated AC Output Power: 5kWMax. AC Output Apparent Power: 5.5kVARated Output Voltage Range: 220 / 230V (0.85Un – 1.1Un)Grid Type: L / N / PEGrid Frequency: 50 / 60HzRated Output Current: 22.8A / 21.8AMax. Output Current: 25A / 24APower Factor: 0.8 Leading to 0.8 LaggingTotal Harmonic Distortion (THDi): <3� Injection Current: <0.5�ficiency:Max. Efficiency: 97.5%Euro Efficiency: 97.0%MPPT Efficiency: >99%Protection Features:DC Reverse Polarity ProtectionAC Output Overcurrent ProtectionAC Output Overvoltage ProtectionAC Output Short Circuit ProtectionThermal ProtectionDC Terminal Insulation Impedance MonitoringDC Component MonitoringGround Fault Current MonitoringPower Network MonitoringAnti-Islanding ProtectionEarth Fault DetectionOvervoltage Load Drop ProtectionResidual Current Detection (RCD)Surge Protection: Type II DC / Type II ACInterface & Communication:Communication Interface: RS485 / RS232Monitoring Options: GPRS / WiFi / Bluetooth / 4G / LAN OptionalGeneral Data:Operating Temperature Range: -25°C to 60°CDerating Temperature: Above 45°CPermissible Humidity: 0 – 100%Max. Operating Altitude: 3000mNoise Level: ≤35dBProtection Degree: IP65Inverter Topology: Non-IsolatedDimensions (W × H × D): 305 × 280 × 180 mmWeight: 7.7kgCooling Method: Natural CoolingStandards & Certification:Grid Standards: IEC 61727, IEC 62116, EN 50549, NRS 097, RD 140, UNE 217002, G99Safety / EMC: IEC/EN 61000-6-1/2/3/4, IEC/EN 62109-1/2
